BRC KTM 500cc CARB CONVERSION KIT 2017-2018, BOLT IN

Please Note:

• Due to the value of the kit, it will be shipped on a single small pallet
• Due to the custom nature of the kit there is no warranty implied or given
• Whilst we will do our best to ensure the correct kit is provided, please ensure all parts are correct before beginning assembly
• Due to US - EU model differences, some modifications may be required to mounts, exhaust or other supporting parts
• You will be required to complete a waiver confirming you agree to the above information before the kit is dispatched

Application

• KTM 250/300 EXC/XC-W 2017-2018 CARB

Features

• PERFORMANCE 510cc of arm-stretching performance. 60+ HP, 50+ Ft Lbs torque.
• POWER VALVE Simple, pneumatic power valve system for linear, smooth power delivery.
• TRANSMISSION Accepts your donor 5- or 6-speed transmission.
• STARTING Both kick start and electric start compatible. Every engine comes with a decomp button to make starting this big bore easier.
• EXHAUST Every kit comes with a pipe and silencer
• VIBRATIONS Bad vibrations are cancelled out with our integral counter balance shaft.
• CARBURATION Contrary to popular belief, the stock 36 or 38mm carburetor is the best fit for your BRC500

Spec

• Bore: 89mm
• Stroke: 82mm
• Displacement: 510cc
• Compression Ratio: 12.5:1
• Squish: 1.47-2.00mm
• Primary Ratio: 2.25 (72:32)
