CAMSHAFT 08-14 RMZ450 EXHAUST, HOTCAMS 2267-1E

SUZUKI
RM-Z450 RMZ450 2008 - 2014,

Hot Cams Stage 1 Cam 2267-1E

Stage 1 ITR exhaust cam. Dual cam engine. Good low end and midrange gains. Uses stock valve springs. Uses stock auto decompression mechanism.

Extract maximum performance from your engine Hot Cams provide increased intake and exhaust duration for improved breathability and more horsepower Provides significantly more mid-range punch and top-end speed for most models Core trade-in not required so you can keep the original camshaft Dual-cam motor; exhaust Good low-end and mid-range gain Use stock valve springs Uses stock auto-decompression mechanism

Specs: Exhaust Lift: 9.7mm Exhaust Duration (@1mm): 238 degrees

Part No. 56-C214.EX (oro2u.com)

Technical Specifications:

Exhaust Duration (Degrees at 1mm):

238.00

Exhaust Lift (mm):

9.70

Exhaust Lobe Center (Degrees):

100.00

Exhaust Valve Lash (mm):

.20

Intake Duration (Degrees at 1mm):

.00

Intake Lift (mm):

.00

Intake Lobe Center (Degrees):

.00

Intake Valve Lash (mm):

.00

Shim Kit:

HCSHIM02
