PISTON KIT 05-09 CR250 66.40 C, WOSSNER 8171DC HONDA MX

Piston Kit 66.42mm Bore 66.37 Wossner 8171DC (+0.02)

HONDA
CR250R 2005 - 2007,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

Part No. 56-W860+00C.WO (oro2u.com)
Wossner Piston Honda CR250R 66.4 mm Bore (PN# 8171DC)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RDB6640
Rod P/N P2020

Display (cm3) 249
Hub stroke (mm) 72.00
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3) -
Compression height (mm) 38.00
Theorectical weight (G)

- 2005 Honda CR 250 R - 2006 Honda CR 250 R - 2007 Honda CR 250 R
