PISTON KIT 2015 KX450F 96.00 A, WOSSNER 8920DA KAWASAKI 13001-0766

Piston kit 96mm Bore 95.98 Wossner 8920DA (STD)

KAWASAKI
KX450F 2015,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany

Part No. 56-W330.A.WO (oro2u.com)
Wossner Piston Kawasaki KX450F 96mm Bore (PN# 8920DA)

Display (cm3) 449
Hub stroke (mm) 62.10
Clearance (mm) 0.05
Wossner compression Ratio: OEM
OEM Compression ratio: 12.80:1
Dome volume (cm3) +0.90
Compression height (mm) 23.70
Theorectical weight (G) 259.00

Cross reference numbers ONLY.
13001-0766,   40125M09603
